Edison NCLR70 NCLR Fuse - 70 Amp - Fast Acting
Normally In Stock
Code: 490471
Edison NCLR70 NCLR fuse, 70 A, -40° to 85°C, Class RK1, Non-indicating, 200 kAIC, Glass melamine tube, Standard, 5, 250 V
Condition: New
Usually ships same day or next day$219.41
Sale Price
$182.84
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Edison NCLR70 NCLR fuse, 70 A, -40° to 85°C, Class RK1, Non-indicating, 200 kAIC, Glass melamine tube, Standard, 5, 250 V
Specifications
Fuse Voltage Rating
250 Volts
Fuse Type (UL)
Class RK1
Fuse Response Time
Fast Acting
Manufacturer
Edison
Fuse Amperage Rating
70 Amp
Component
Fuse
Features
Single-element, fast-acting fuses with minimal timedelay.
Provides a high degree of short-circuit current-limitation (component protection).
Particularly suited for circuits and loads with no heavy surge currents of motors, transformers, solenoids, and welders.
NCLR fuses are commonly used to protect circuit breakers with lower interrupting ratings.
If used in circuits with surge currents (motors, etc.) must be sized to prevent unwanted opening and thus only provide short-circuit protection.
Incorporates Class R rejection feature. Can be inserted in non-rejection type fuse holders. Thus, can physically and electrically replace fast-acting Class H, K1, K5, RK5, and other fast-acting fuses.
