nVent Hoffman A72XM2818SSN4 Stainless Steel Disconnect Enclosure
Normally In Stock
Code: 4799
nVent Hoffman A72XM2818SSN4 Stainless Steel Disconnect Enclosure Preferred-Cutout. 72" x 28" x 18" (HxWxD) One Door 304 Stainless Steel Type 4x Free-Stand(Floor Mount) Disconnect Enclosure with heavy duty continuous hinges and 3-point latch with padlocking Powerglide handle. (DOES NOT INCLUDE BACK PANEL)
Condition: New
Usually ships Same Day or Next DayDOES NOT INCLUDE BACK PANEL
$18362.09
Sale Price
$15301.74
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
nVent Hoffman A72XM2818SSN4 Stainless Steel Disconnect Enclosure This disconnect enclosure is designed to house electronic controls and components. It provides protection from noncorrosive or mildly corrosive elements in both indoor and outdoor environments. Typical applications are in the food and beverage, packaging, water, petroleum and chemical processing industries. Designed to house the most popular disconnect switches and circuit breakers.
Specifications
Enclosure Environment Rating
Outdoor-Indoor
Enclosure Hinge Type
Standard Hinge
Enclosure Interior Color
White
Enclosure Lock Type
Padlocking
Enclosure Depth
18"
Enclosure Composition
Stainless Steel
Enclosure Latch Type
3 Point
Enclosure NEMA Rating
NEMA Type 4
Enclosure NEMA Rating
NEMA Type 4X
Enclosure Height
72"
Enclosure Width
28"
Component
Disconnect Enclosure
Enclosure Door Type
Solid
Enclosure Mount Type
Wall Mount
Enclosure Number of Doors
1 Door
Enclosure NEMA Rating
NEMA Type 3R
Enclosure NEMA Rating
NEMA Type 12
Cutout Type
Preferred Cutout
Manufacturer
Hoffman
Features
Heavy-duty lifting eyes anchor into reinforced top
Body stiffeners in larger enclosures for extra rigidity
Body flange trough collar excludes liquids and contaminants
Removable centerposts permit easy panel installation
Seams continuously welded and ground smooth
Disconnect enclosure is designed to house electronic controls
Heavy-gauge continuous hinges
Seamless foam-in-place gasket provides oil-tight and dust-tight seal against contaminants
Data pocket is high-impact thermoplastic
Panel supports
Heavy-duty 3-point latching mechanism operated by Type 316L stainless steel PowerGlide padlocking handle on all doors
Accessory mounting channel provided in enclosure to
Removable 10 gauge steel panels mount on collar studs
Master door is far right-hand door on all enclosures
Type 316 stainless steel handle (non-defeater) on slave door
Mechanical interlock activated by master door prevents slave doors from being opened first. Doors can be closed in any order.
Preferred cutout on right flange provides mounting for most disconnect operators
Bonding provision on doors, grounding studs on body
Type 316 stainless steel handle with defeater on master door
Downloads
Hoffman A72XM2818SSN4 2D DXF CAD.zipHoffman A72XM2818SSN4 3D STEP CAD.zipHoffman A72XM2818SSN4 CAD Drawing.zipHoffman A72XM2818SSN4 CSA Certification.pdfHoffman A72XM2818SSN4 Declaration of Compliance.pdfHoffman A72XM2818SSN4 Dimension Drawing.gifHoffman A72XM2818SSN4 Enclosure Alterations Manual.pdfHoffman A72XM2818SSN4 EU Certification.pdfHoffman A72XM2818SSN4 Instruction Manual.pdfHoffman A72XM2818SSN4 Large Enclosure Handling Manual.pdfHoffman A72XM2818SSN4 Spec Sheet.pdfHoffman A72XM2818SSN4 UL Certification.pdfHoffman A72XM2818SSN4 User Manual.pdf
