3M 7000132508 - 3M Heat Shrinkable Cable Breakout Boot HDBB-425-1-250, black, 4-way,outlet
Normally In Stock
Code: 475941
3M Heat Shrinkable Cable Breakout Boot HDBB-425-1-250, black, 4-way,outlet - 7000132508
Condition: New
CALL FOR LEAD TIMEMUST ORDER A MINIMUM OF $500 FROM 3M FOR PRODUCT TO SHIP
$65.38
Sale Price
$54.48
SOLD BY THE CASE (1 Case = 1 Each)
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Tubing & Molded Parts, 3M,Catalog Number: HDBB-425-1-250,Maximum Operating Temperature: 135 ℃,Product Color: Black,Material: Semi-rigid, Flame Retardant Polyolefin,Inner Diameter Before Shrink (Metric): 30.5 mm,Inner Diameter Before Shrink (Imperial): 1.2 in,Inner Diameter After Shrink (Metric): 13.5 mm,Inner Diameter After Shrink (Imperial): 0.53 in,Flame Retardant: Yes,Heat Shrink Type: Heat Shrink Molded Shapes,Operating Temperature (Celsius): -30 up to +135°C, Cable & Wire Accessory,Minimum Shrink Temperature: 120 ℃,UV Resistant: Yes,Dielectric Strength: 10 kV / mm,Model: Cold-shrink,Indoor/Outdoor: Both,Shrink Type: Heat Shrink,Cable End Expanded: 2.65 in,Cable End Recovered: 1.4 in,Number of Outlets: 4,Conductor Legs Expanded: 1.2 in,Outlet Style: 4-Way,Conductor Legs Recovered: 0.53 in,Outer Diameter Before Shrink (Imperial): 2.65 in,Outer Diameter Before Shrink (Metric): 67.3 mm,Transition Type: 1 - 4 Breakout,Outer Diameter After Shrink (Imperial): 1.4 in,Outer Diameter After Shrink (Metric): 35.6 mm - 7000132508
Specifications
Color
Black
Manufacturer
3M
Maximum Operating Temperature (Celsius)
135 °C
Flame Retardant
Yes
Component
Tubing & Molded Part
Heat Shrink Type
Heat Shrink Molded Shapes
Material
Flame Retardant Polyolefin
Features
Ensures excellent insulation and void-free sealing of cable breakouts
Internal coating of adhesive offers reliable environmental sealing
Provides maximum electrical and mechanical protection
Semi-rigid, flame-retardant polyolefin construction
RoHS 2011/65/EU Compliant
