3M 7010320995 - 3M Heat Shrink Thin-Wall Tubing FP-301-1/8-48"-White-250 Pcs, 48 in length sticks
Normally In Stock
Code: 475719
3M Heat Shrink Thin-Wall Tubing FP-301-1/8-48"-White-250 Pcs, 48 in length sticks - 7010320995
Condition: New
CALL FOR LEAD TIMEMUST ORDER A MINIMUM OF $500 FROM 3M FOR PRODUCT TO SHIP
$690.48
Sale Price
$575.40
SOLD BY THE CASE (1 Case = 250 Each)
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
3MFP0.125WT48"L is a single thin wall polyolefin heat shrink tubing designed for various applications. With an operating temperature range of -55 to 135 degrees Celsius (-67 °F to 275 °F) and a 2:1 shrink ratio, this tubing provides excellent protection. It is flame retardant and non-corrosive, making it safe and durable. The tubing has an inner diameter before shrinking of 0.125 in (3.18 mm) and an inner diameter after shrinking of 0.062 in (1.57 mm). It is available in 48 in (1.22 m) sticks and is approved by CSA and UL. The 3MFP0.125WT48"L is ideal for access networks, long-haul/metro loop networks, and wireless networks. - 7010320995
Specifications
Color
White
Manufacturer
3M
Maximum Operating Temperature (Fahrenheit)
275 °F
Maximum Operating Temperature (Celsius)
135 °C
Overall Length (Imperial)
48 In
Flame Retardant
Yes
Component
Tubing & Molded Part
Heat Shrink Type
Single-Wall Polyolefin Heat Shrink Tubing
Material
Polyolefin
Tubing Type
Single (Thin) Wall
Features
A VARIETY OF APPLICATIONS: Offers a 2:1 shrink-fit ratio and serves as protection in wire-harnessing, split-resistance covering, wire marking, wire bundling, and component packaging
FLAME-RETARDANT TUBING: For applications up to 600V (clear is not flame retardant)
HIGH-STRENGTH PROTECTION: Balances electrical, physical, and chemical properties for various industrial and military applications
FOR DEMANDING CONDITIONS: Performs at an operating temperature up to 275 °F (135 °C)
KEY SPECIFICATIONS: UL Listed, File E-39100, SAE AS23053/5, Class 1 (all colors), Class 2 (clear), CSA Certified, and RoHS 2011/65/EU Compliant
