3M 7000133417 - Scotchlok™ Ring Nylon Insulated, 100/bottle, MNG14-516R/SX, standard-style ring tongue fits around the stud
Normally In Stock
Code: 474954
Scotchlok™ Ring Nylon Insulated, 100/bottle, MNG14-516R/SX, standard-style ring tongue fits around the stud - 7000133417
Condition: New
CALL FOR LEAD TIMEMUST ORDER A MINIMUM OF $500 FROM 3M FOR PRODUCT TO SHIP
$937.08
Sale Price
$780.90
SOLD BY THE CASE (1 Case = 500 Each)
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Scotchlok™ Ring Terminals, with the catalog number MNG14-516R/SX, are designed for maximum performance. They have an overall length of 1.09 in (27.68 mm), an overall width of 0.47 in (11.93 mm), and a connection width of 0.315 in (8 mm). With a maximum operating temperature of 105 ℃, the blue terminals are made of nylon insulation material. They can accommodate conductor sizes ranging from 16 AWG (1.31 mm²) to 14 AWG (2.08 mm²). - 7000133417
Specifications
Color
Blue
Component
Ring Terminal
Manufacturer
3M
Maximum Operating Temperature (Celsius)
105 °C
Sub Brand
Scotchlok™
Maximum Conductor Size (Imperial)
14 AWG
Minimum Conductor Size (Imperial)
16 AWG
Insulation Material
Nylon
Maximum Conductor Size (Metric)
2.08 mm²
Minimum Conductor Size (Metric)
1.31 mm²
Terminal Type
Ring
Overall Length (Imperial)
1.09 In
Overall Length (Metric)
27.68 mm
Features
Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
Funnel-designed, seamless brass sleeve offers easy insertion of wires
Standard-style ring tongue fits around the stud
Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
600V-rated for building wire and 1000V for signs, fixtures or luminaires
UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
