Code: 474838
3M 7000132247 - Scotchlok™ Ring Tongue, Nylon Insulated w/Insulation Grip,MNG14-10RK, Stud Size 10
Normally In Stock
Scotchlok™ Ring Tongue, Nylon Insulated w/Insulation Grip,MNG14-10RK, Stud Size 10 - 7000132247
Condition: New
CALL FOR LEAD TIMEMUST ORDER A MINIMUM OF $500 FROM 3M FOR PRODUCT TO SHIP
$809.24
Sale Price
$674.37
SOLD BY THE CASE (1 Case = 1000 Each)
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
ring terminal, with 3Mcatalog number MNG14-10RK, is from the Scotchlok™ brand. It has an overall length of 0.91 inches and can withstand a maximum operating temperature of 105°C. The terminal is blue in color and is suitable for conducting wires with a size ranging from 14 AWG to 16 AWG. Made from nylon with an insulation grip, it has an overall width of 0.33 inches and a connection width of 0.19 inches (4.826 mm). - 7000132247
Specifications
Color
Blue
Component
Ring Terminal
Manufacturer
3M
Sub Brand
Scotchlok™
Maximum Conductor Size (Imperial)
14 AWG
Minimum Conductor Size (Imperial)
16 AWG
Insulation Material
Nylon With Insulation Grip
Maximum Conductor Size (Metric)
2.08 mm²
Minimum Conductor Size (Metric)
1.31 mm²
Overall Length (Imperial)
0.91 In
Terminal Type
Ring
Features
Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
Funnel-designed, seamless brass sleeve offers easy insertion of wires
Standard-style ring tongue fits around the stud
Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
600V-rated for building wire and 1000V for signs, fixtures or luminaires
UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
