Code: 474832
3M 7000133296 - Scotchlok™ Ring Nylon Insulated, 50/bottle, MNG10-8RX, standard-style ring tongue fits around the stud
Normally In Stock
Scotchlok™ Ring Nylon Insulated, 50/bottle, MNG10-8RX, standard-style ring tongue fits around the stud - 7000133296
Condition: New
CALL FOR LEAD TIMEMUST ORDER A MINIMUM OF $500 FROM 3M FOR PRODUCT TO SHIP
$86.26
Sale Price
$71.88
SOLD BY THE CASE (1 Case = 500 Each)
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Scotchlok™ Ring Terminals, catalog number MNG10-8RX, are yellow in color and made with nylon insulation material. They have an overall length of 1.03 inches (26.16 mm) and a maximum operating temperature of 105 ℃. These terminals have a maximum conductor size of 10 AWG (5.26 mm²) and a minimum conductor size of 12 AWG (3.31 mm²). The overall width is 0.38 inches (9.65 mm) and the connection width is 0.164 inches (4.166 mm). - 7000133296
Specifications
Color
Yellow
Component
Ring Terminal
Manufacturer
3M
Sub Brand
Scotchlok™
Maximum Conductor Size (Imperial)
10 AWG
Minimum Conductor Size (Imperial)
12 AWG
Insulation Material
Nylon
Overall Length (Imperial)
1.03 In
Maximum Conductor Size (Metric)
5.26 mm²
Minimum Conductor Size (Metric)
3.31 mm²
Overall Length (Metric)
26.16 mm
Terminal Type
Ring
Features
Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
Funnel-designed, seamless brass sleeve offers easy insertion of wires
Standard-style ring tongue fits around the stud
Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
600V-rated for building wire and 1000V for signs, fixtures or luminaires
UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
