Code: 474830
3M 7000133297 - Scotchlok™ Ring Nylon Insulated, 50/bottle, MNG10-10RX, standard-style ring tongue fits around the stud
Normally In Stock
Scotchlok™ Ring Nylon Insulated, 50/bottle, MNG10-10RX, standard-style ring tongue fits around the stud - 7000133297
Condition: New
CALL FOR LEAD TIMEMUST ORDER A MINIMUM OF $500 FROM 3M FOR PRODUCT TO SHIP
$862.61
Sale Price
$718.84
SOLD BY THE CASE (1 Case = 500 Each)
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Scotchlok™ Ring Terminals (MNG10-10RX) are designed for reliable electrical connections. With an overall length of 1.03 inches (26.16 mm) and a maximum operating temperature of 105 ℃, these yellow terminals accommodate a range of conductor sizes, from 10 AWG to 12 AWG (5.26 mm² to 3.31 mm²). Made with nylon insulation, these terminals feature a ring design and a stud size of #10, with a minimal stud diameter of 5 mm (4.826 mm connection width). - 7000133297
Specifications
Color
Yellow
Component
Ring Terminal
Manufacturer
3M
Sub Brand
Scotchlok™
Maximum Conductor Size (Imperial)
10 AWG
Minimum Conductor Size (Imperial)
12 AWG
Insulation Material
Nylon
Overall Length (Imperial)
1.03 In
Maximum Conductor Size (Metric)
5.26 mm²
Minimum Conductor Size (Metric)
3.31 mm²
Overall Length (Metric)
26.16 mm
Terminal Type
Ring
Features
Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
Funnel-designed, seamless brass sleeve offers easy insertion of wires
Standard-style ring tongue fits around the stud
Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
600V-rated for building wire and 1000V for signs, fixtures or luminaires
UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
