Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Code: 474284
3M 7000006044 - 3M Motor Lead Pigtail Splice 5324, 5-8 kV, 250-500 kcmil (feeder), 4/0 AWG-500 kcmil (motor lead)
Normally In Stock
3M Motor Lead Pigtail Splice 5324, 5-8 kV, 250-500 kcmil (feeder), 4/0 AWG-500 kcmil (motor lead) - 7000006044
Condition: New
CALL FOR LEAD TIMEMUST ORDER A MINIMUM OF $500 FROM 3M FOR PRODUCT TO SHIP
$877.44
Sale Price
$731.20
SOLD BY THE CASE (1 Case = 1 Kit)
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
3MMotor Lead Splices, catalog number 5324, are designed for polymeric insulated cables. They are suitable for indoor use and can handle a maximum voltage of 5/8 kV. The splices accommodate conductor sizes ranging from 4/0 AWG to 500 kcmil. The connection type includes both non-shielded and shielded pigtail options. The kit does not include a lug/stem connector, and the lug cover length ranges from 10.5 to 11.5 inches. - 7000006044
Specifications
Manufacturer
3M
Maximum Conductor Size (Imperial)
500 Kcmil
Maximum Conductor Size (Metric)
240 mm²
Minimum Conductor Size (Imperial)
4/0 AWG
Minimum Conductor Size (Metric)
95 mm²
Component
Motor Lead Splice
Splice Type
Pigtail Only
