3M 7000005879 - Scotchlok™ Electrical IDC 567-BIN, Run and Tap, Flame Retardant, Brown, 18-14 AWG (Tap), 12-10 AWG (Run)
Normally In Stock
Code: 474235
Scotchlok™ Electrical IDC 567-BIN, Run and Tap, Flame Retardant, Brown, 18-14 AWG (Tap), 12-10 AWG (Run) - 7000005879
Condition: New
CALL FOR LEAD TIMEMUST ORDER A MINIMUM OF $500 FROM 3M FOR PRODUCT TO SHIP
$726.97
Sale Price
$605.81
SOLD BY THE CASE (1 Case = 1000 Each)
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Scotchlok™ IDC Taps & Splices, with 3MCatalog Number 567-BIN, is a reliable and efficient wire connector. It has a maximum operating temperature of 105℃ (221℉), supporting low voltage applications. With a maximum conductor size of 10 AWG (Run) and 14 AWG (Tap), it is suitable for various wiring needs. The connector is made of FR Polypropylene insulator and tin-plated brass U-contact, ensuring durability and flame retardancy. It is compatible with wire sizes ranging from 12 AWG to 18 AWG (Run) and 18 AWG to 1 mm² (Tap). The connector comes in brown color, providing a secure and neat connection. The product meets all necessary safety standards, including UL File Number E23438 and CSA File Number LR15503, LR32411. It can be easily installed using 3MCrimping Tool E-9BM or 9" Lineman's Pliers. Each package includes 1000 connector units. - 7000005879
Specifications
Color
Brown
Manufacturer
3M
Maximum Operating Temperature (Fahrenheit)
221 °F
Maximum Operating Temperature (Celsius)
105 °C
Sub Brand
Scotchlok™
Component
IDC Taps & Splice
Insulation Material
Polypropylene
Material
Insulator: FR Polypropylene
Material
U-Contact: Tin-Plated Brass
Maximum Conductor Size (Imperial)
10 AWG (Run)
Maximum Conductor Size (Imperial)
14 AWG (Tap)
Maximum Conductor Size (Metric)
2.5 mm² (Tap)
Maximum Conductor Size (Metric)
6 mm² (Run)
Minimum Conductor Size (Imperial)
12 AWG (Run)
Minimum Conductor Size (Imperial)
18 AWG (Tap)
Minimum Conductor Size (Metric)
1 mm² (Tap)
Minimum Conductor Size (Metric)
4 mm² (Run)
Features
Brown polypropylene-insulated connector
Suitable for general purpose electrical connections on an auto, boat, van or trailer
Accommodates 18 to 16 AWG solid/stranded or 14 AWG stranded
UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
