3M 7000132250 - Scotchlok™ Fork, Nylon Insulated w/Insulation Grip MNG14-10FK, 16-14 AWG
Normally In Stock
Code: 473888
Scotchlok™ Fork, Nylon Insulated w/Insulation Grip MNG14-10FK, 16-14 AWG - 7000132250
Condition: New
CALL FOR LEAD TIMEMUST ORDER A MINIMUM OF $500 FROM 3M FOR PRODUCT TO SHIP
$726.97
Sale Price
$605.81
SOLD BY THE CASE (1 Case = 1000 Each)
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Scotchlok™ Fork Terminal, 3MCatalog Number MNG14-10FK, is a blue-colored product made of ETP Copper material. It has an overall length of 0.91 inches and a maximum operating temperature of 105 ℃ (221 ℉). With a maximum conductor size of 14 AWG (2.08 mm²) and a minimum conductor size of 16 AWG (1.31 mm²), this fork terminal is suitable for a variety of applications. It features a nylon insulation material with an insulation grip, and its terminal type is fork. The overall width is 0.34 inches and the terminal has a barrel length of 0.25 inches with a barrel inside diameter of 0.09 inches. The maximum recommended voltage rating is 600 V. - 7000132250
Specifications
Color
Blue
Manufacturer
3M
Maximum Operating Temperature (Fahrenheit)
221 °F
Maximum Operating Temperature (Celsius)
105 °C
Sub Brand
Scotchlok™
Terminal Style
Standard
Maximum Conductor Size (Imperial)
14 AWG
Minimum Conductor Size (Imperial)
16 AWG
Component
Fork Terminals
Material
ETP Copper
Insulation Material
Nylon With Insulation Grip
Terminal Type
Fork
Maximum Conductor Size (Metric)
2.08 mm²
Minimum Conductor Size (Metric)
1.31 mm²
Overall Length (Imperial)
0.91 In
Features
Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
Funnel-designed, seamless brass sleeve offers easy insertion of wires
Wider tongue design for use on free-standing studs
Electrolytic copper construction offers good conductivity
Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
600V-rated for building wire and 1000V for signs, fixtures or luminaires
UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
