3M 7000133284 - Scotchlok™ Fork Nylon Insulated, 100/bottle, MNG14-6FX, wider-tongue,design for use on free-standing studs
Normally In Stock
Code: 473850
Scotchlok™ Fork Nylon Insulated, 100/bottle, MNG14-6FX, wider-tongue,design for use on free-standing studs - 7000133284
Condition: New
CALL FOR LEAD TIMEMUST ORDER A MINIMUM OF $500 FROM 3M FOR PRODUCT TO SHIP
$705.28
Sale Price
$587.73
SOLD BY THE CASE (1 Case = 500 Each)
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Scotchlok™ Fork Terminals (MNG14-6FX) are blue, standard fork terminals made of ETP Copper. They have an overall length of 0.91in (23.11mm) and a maximum operating temperature of 105℃ (221℉). These terminals can accommodate conductor sizes ranging from 14 AWG to 16 AWG and have an insulation grip made of nylon. They are suitable for use in applications with a maximum voltage rating of 600V. - 7000133284
Specifications
Color
Blue
Manufacturer
3M
Maximum Operating Temperature (Fahrenheit)
221 °F
Maximum Operating Temperature (Celsius)
105 °C
Sub Brand
Scotchlok™
Terminal Style
Standard
Maximum Conductor Size (Imperial)
14 AWG
Minimum Conductor Size (Imperial)
16 AWG
Component
Fork Terminals
Material
ETP Copper
Insulation Material
Nylon With Insulation Grip
Terminal Type
Fork
Maximum Conductor Size (Metric)
2.08 mm²
Minimum Conductor Size (Metric)
1.31 mm²
Overall Length (Imperial)
0.91 In
Overall Length (Metric)
23.11 mm
Features
Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
Funnel-designed, seamless brass sleeve offers easy insertion of wires
Wider tongue design for use on free-standing studs
Electrolytic copper construction offers good conductivity
Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
600V-rated for building wire and 1000V for signs, fixtures or luminaires
UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
