3M 7100163963 - Scotchlok™ Flanged Block Fork, Vinyl Insulated Butted Seam,MVU18-10FFBK, 22-18 AWG
Normally In Stock
Code: 473841
Scotchlok™ Flanged Block Fork, Vinyl Insulated Butted Seam,MVU18-10FFBK, 22-18 AWG - 7100163963
Condition: New
CALL FOR LEAD TIMEMUST ORDER A MINIMUM OF $500 FROM 3M FOR PRODUCT TO SHIP
$500.10
Sale Price
$416.75
SOLD BY THE CASE (1 Case = 1000 Each)
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Scotchlok™ Fork Terminals (3MCatalog Number: MVU18-10FFBK) are designed for reliable connections. These terminals have an overall length of 0.85 in and can accommodate a maximum conductor size of 18 AWG. They are made with vinyl insulation material and have a flanged block terminal style. With an overall width of 0.3 in and a connection width of 0.19 in (4.826 mm), these terminals offer a secure and efficient solution for various applications. - 7100163963
Specifications
Manufacturer
3M
Sub Brand
Scotchlok™
Maximum Conductor Size (Imperial)
18 AWG
Minimum Conductor Size (Imperial)
22 AWG
Insulation Material
Vinyl
Component
Fork Terminals
Maximum Conductor Size (Metric)
.0823 mm²
Terminal Type
Fork
Minimum Conductor Size (Metric)
0.326 mm²
Overall Length (Imperial)
0.85 In
Terminal Style
Flanged Block
Features
Vinyl-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
Funnel-designed, polyvinyl chloride sleeve offers easy insertion of wires
Suitable for use in a terminal block
Electrolytic copper construction offers good conductivity
Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
600V-rated for building wire and 1000V for signs, fixtures or luminaires
UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
