3M 7000031397 - Scotchlok™ Copper One Hole Lug 30041, up to 35 kV, 3/0 AWG, Stud,Size 1/2 (12), Orange
Normally In Stock
Code: 473597
Scotchlok™ Copper One Hole Lug 30041, up to 35 kV, 3/0 AWG, Stud,Size 1/2 (12), Orange - 7000031397
Condition: New
CALL FOR LEAD TIMEMUST ORDER A MINIMUM OF $500 FROM 3M FOR PRODUCT TO SHIP
$166.99
Sale Price
$139.16
SOLD BY THE CASE (1 Case = 10 Each)
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Scotchlok™ Compression Lugs, 3MCatalog Number 30041, are copper lugs designed for use with copper conductors only. They have a maximum operating voltage of 35 Kilovolt and can accommodate a maximum conductor size of 3/0 AWG. These lugs have a standard barrel style with an overall length of 2.63 inches (66.8 mm). Each lug has one hole for the stud size of 1/2 inch. The pack includes 10 lugs with a product color of orange. - 7000031397
Specifications
Color
Orange
Component
Compression Lug
Material
Copper
Manufacturer
3M
Sub Brand
Scotchlok™
Maximum Conductor Size (Imperial)
3/0 AWG
Overall Length (Imperial)
2.63 In
Overall Length (Metric)
66.8 mm
Features
Standard barrel ensures a secure fit and offers reliable performance
Barrel has colored stripes that help to indicate the wire range
Suitable for indoor and outdoor applications
Made of copper for good conductivity and tin plating for corrosion resistance
Rated up to 35 kV
UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
