Compression Lugs product from 3M, catalog number 30036, is part of the Scotchlok™ brand. It is made of copper with a black color. The overall length is 2.37 inches (60.2 mm) and it has a standard barrel style with a length of 0.87 inches (22.1 mm). It is suitable for use with copper conductors only, with a maximum conductor size of 2/0 AWG (70 mm²). It has one hole for compression connection and is compatible with 3/8-inch stud sizes. The lug has an inner diameter of 0.43 inches (11.2 mm) and an outer diameter of 0.56 inches. The lug is sold in a case of 10 and the pad dimensions are 0.81 inches wide and 1.11 inches long (20.7 mm wide and 28.2 mm long). It has a maximum operating voltage of 35 Kilovolt. The lug is designed for electrical applications where compression termination is required. - 7000031396
