3M 7000031393 - Scotchlok™ Copper One Hole Lug 30028, up to 35 kV, 1 AWG, Stud Size,3/8 (10), Green
Normally In Stock
Code: 473593
Scotchlok™ Copper One Hole Lug 30028, up to 35 kV, 1 AWG, Stud Size,3/8 (10), Green - 7000031393
Condition: New
CALL FOR LEAD TIMEMUST ORDER A MINIMUM OF $500 FROM 3M FOR PRODUCT TO SHIP
$96.86
Sale Price
$80.72
SOLD BY THE CASE (1 Case = 10 Each)
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Scotchlok™ Compression Lugs (30028) are green in color and made of copper material. They have an overall length of 1.97 in (50 mm) and a barrel length of 0.81 in (20.7 mm). The lug is designed for use with copper conductors only, with a maximum conductor size of 1 AWG (50mm²). It has one hole and is compatible with 3/8 inch studs. Each case quantity contains 10 compression lugs. Maximum operating voltage is 35 Kilovolt. - 7000031393
Specifications
Color
Green
Component
Compression Lug
Material
Copper
Manufacturer
3M
Sub Brand
Scotchlok™
Maximum Conductor Size (Imperial)
1 AWG
Overall Length (Imperial)
1.97 In
Overall Length (Metric)
50 mm
Features
Standard barrel ensures a secure fit and offers reliable performance
Barrel has colored stripes that help to indicate the wire range
Suitable for indoor and outdoor applications
Made of copper for good conductivity and tin plating for corrosion resistance
Rated up to 35 kV
UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
