Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
3M 7000031388 - Scotchlok™ Copper One Hole Lug 30018, up to 35 kV, 4 AWG, Stud Size,#10 (5), Gray
Normally In Stock
Code: 473586
Scotchlok™ Copper One Hole Lug 30018, up to 35 kV, 4 AWG, Stud Size,#10 (5), Gray - 7000031388
Condition: New
CALL FOR LEAD TIMEMUST ORDER A MINIMUM OF $500 FROM 3M FOR PRODUCT TO SHIP
$316.14
Sale Price
$263.45
SOLD BY THE CASE (1 Case = 50 Each)
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Product type: Compression Lugs, Scotchlok™,3MCatalog Number: 30018,Overall Length (Imperial): 1.94 in,Barrel Style: Standard Barrel,Material: Copper,Product Color: Gray,Maximum Conductor Size (Imperial): 4 AWG,Maximum Operating Voltage: 35 Kilovolt,Stud Sizes: #10,Number of Stud Holes: 1,Compatible Conductor Size (Metric): 25 mm²,Overall Length (Metric): 49.3 mm,Barrel Length (Imperial): 0.75 in,Barrel Length (Metric): 19.1 mm,Inside Diameter (Imperial): 0.24 in,Inside Diameter (Metric): 6.2 mm,Outer Diameter (Imperial): 0.34 in,Pad Length (Imperial): 0.89 in,Pad Length (Metric): 22.6 mm,Pad Width: 0.48 in,Pad Width (Metric): 12.3 mm,Center of Hole to End of Pad: 0.37 Inch,Center of Hole to End of Pad (Metric): 9.5 mm,For Use With: Copper Conductor Only,Product Series: 30000,Case Quantity: 50, Compression Lugs by Scotchlok™ are designed for use with copper conductors only. With a maximum operating voltage of 35 Kilovolt, these lugs are suitable for a variety of electrical applications. They feature a standard barrel style and can accommodate stud sizes up to #10. The lug is made of copper and has a gray color. It has an overall length of 1.94 inches (49.3 mm) and a maximum conductor size of 4 AWG. Each case contains 50 compression lugs. - 7000031388
Specifications
Color
Gray
Component
Compression Lug
Material
Copper
Manufacturer
3M
Sub Brand
Scotchlok™
Maximum Conductor Size (Imperial)
4 AWG
Overall Length (Imperial)
1.94 In
Overall Length (Metric)
49.3 mm
Features
Standard barrel ensures a secure fit and offers reliable performance
Barrel has colored stripes that help to indicate the wire range
Suitable for indoor and outdoor applications
Made of copper for good conductivity and tin plating for corrosion resistance
Rated up to 35 kV
UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
