Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Code: 473577
3M 7000031403 - Scotchlok™ Copper One Hole Long Barrel Lug 31053, up to 35 kV, 300 kcmil, White
Normally In Stock
Scotchlok™ Copper One Hole Long Barrel Lug 31053, up to 35 kV, 300 kcmil, White - 7000031403
Condition: New
CALL FOR LEAD TIMEMUST ORDER A MINIMUM OF $500 FROM 3M FOR PRODUCT TO SHIP
$243.54
Sale Price
$202.95
SOLD BY THE CASE (1 Case = 10 Each)
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Scotchlok™ Compression Lugs are long barrel connectors designed for use with copper conductors only. They have a maximum operating voltage of 35 Kilovolt and a maximum conductor size of 300 kcmil. The lugs have a one-hole connector with an inner diameter of 0.65 in and an outer diameter of 0.81 in. They are 3.78 in long and come in a case of 10. The lugs are compatible with 1/2 inch stud sizes and have a center of hole to center of hole distance of 0.531 in. - 7000031403
Specifications
Color
White
Component
Compression Lug
Material
Copper
Manufacturer
3M
Sub Brand
Scotchlok™
Maximum Conductor Size (Imperial)
300 Kcmil
Overall Length (Imperial)
3.78 In
Overall Length (Metric)
96 mm
Features
Long barrel ensures a secure fit and offers reliable performance
Barrel has colored stripes that help to indicate the wire range
Suitable for indoor and outdoor applications
Made of copper for good conductivity and tin plating for corrosion resistance
Rated for 35 kV applications
UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
