Compression Lugs product, catalog number 31049, from Scotchlok™ is designed for use with copper conductors only. It has a long barrel style with an overall length of 3.38 inches (85.8 mm) and a maximum conductor size of 250 kcmil. The lug is made of copper and has a yellow color. It has a one-hole connector description and is suitable for a maximum operating voltage of 35 Kilovolt. The lug has an inner diameter of 0.59 inches (15.1 mm) and an outer diameter of 0.75 inches. It is compatible with a 1/2 inch stud size and has a center of hole to end of pad distance of 0.53 inches (13.4 mm). The lug comes in a case quantity of 10. - 7000031402
