Code: 473574
3M 7000031400 - Scotchlok™ Copper One Hole Long Barrel Lug 31041, up to 35 kV, 3/0 AWG, Orange
Normally In Stock
Scotchlok™ Copper One Hole Long Barrel Lug 31041, up to 35 kV, 3/0 AWG, Orange - 7000031400
Condition: New
CALL FOR LEAD TIMEMUST ORDER A MINIMUM OF $500 FROM 3M FOR PRODUCT TO SHIP
$195.01
Sale Price
$162.51
SOLD BY THE CASE (1 Case = 10 Each)
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Scotchlok™ Compression Lugs (3MCatalog Number 31041) are long barrel connectors made of copper. They have an overall length of 3.13 in (79.5 mm) and a maximum conductor size of 3/0 AWG. These orange-colored lugs have a pad width of 0.91 in (23 mm) and are compatible with copper conductors only. They have a stud size of 1/2 inch and a maximum operating voltage of 35 Kilovolt. The lug's barrel length measures 1.44 in (36.5 mm) and its inner and outer diameters are 0.49 in (12.4 mm) and 0.62 in respectively. These compression lugs have a one-hole connector description and can be purchased in a case quantity of 10. - 7000031400
Specifications
Color
Orange
Component
Compression Lug
Material
Copper
Manufacturer
3M
Sub Brand
Scotchlok™
Maximum Conductor Size (Imperial)
3/0 AWG
Overall Length (Imperial)
3.13 In
Overall Length (Metric)
79.5 mm
Features
Long barrel ensures a secure fit and offers reliable performance
Barrel has colored stripes that help to indicate the wire range
Suitable for indoor and outdoor applications
Made of copper for good conductivity and tin plating for corrosion resistance
Rated for 35 kV applications
UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
