3M 7100313614 - 3M Electrically Conductive Double-Sided Tape 9772-30, 25 mm x 10 m
Normally In Stock
Code: 473396
3M Electrically Conductive Double-Sided Tape 9772-30, 25 mm x 10 m - 7100313614
Condition: New
CALL FOR LEAD TIMEMUST ORDER A MINIMUM OF $500 FROM 3M FOR PRODUCT TO SHIP
$272.70
Sale Price
$227.25
SOLD BY THE CASE (1 Case = 12 Roll)
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
3M 7100313614 - Conductive Adhesive Transfer Tapes (9772-30) are gold-colored tapes suitable for various applications like chassis, EMI gaskets, shields, flexible printed circuits, and sensors. The product features an acrylic adhesive, copper foil backing, and a total tape thickness of 0.03 mm (1.2 mil) without the liner. It has a maximum operating temperature of 121 ℃ (250 ℉) and can withstand minimum temperatures as low as -40 ℃ (-40 ℉). The tape has an adhesion strength of 1100 gf/in and an electrical resistance of 0.015 Ω in the XY-axis. Shelf life is 12 months.
Specifications
Manufacturer
3M
Adhesive Type
Acrylic
Component
Electrical Tape
Maximum Operating Temperature (Fahrenheit)
250 °F
Maximum Operating Temperature (Celsius)
121 °C
Length (Metric)
10 M
Width (Metric)
25 mm
Sub Component
Conductive Adhesive Transfer Tape
Width (Imperial)
0.984 In
Length (Imperial)
10.936 Yd
Color
Gold
Features
Isotropic XYZ-axis conductivity through the adhesive
Excellent XY-axis electrical resistance
Thin profile
Conformable and bonds quickly
Good EMI shielding in the bond line gap
Improved electrical contact to small-size areas
Good handling and workability
Good passive intermodulation (PIM) performance
