3M 7100313411 - 3M Electrically Conductive Single-Sided Tape 1050TC-25, 500 mm x 30 m
Normally In Stock
Code: 473373
3M Electrically Conductive Single-Sided Tape 1050TC-25, 500 mm x 30 m - 7100313411
Condition: New
CALL FOR LEAD TIMEMUST ORDER A MINIMUM OF $500 FROM 3M FOR PRODUCT TO SHIP
$1152.62
Sale Price
$960.52
SOLD BY THE CASE (1 Case = 1 Roll)
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
3M 7100313411 - Conductive Adhesive Transfer Tapes (Catalog Number 1050TC-25) are gold-colored tapes with acrylic adhesive, designed for various applications such as camera modules, display wraps, EMI shields, and more. With an overall width of 19.685 inches (500 mm) and length of 32.808 yards (30 m), these tapes have a total thickness of 0.023 mm (0.906 mil) without liner. Backed by copper foil, they offer a maximum operating temperature of 121 ℃ (250 ℉) and a minimum operating temperature of -40 ℃ (-40 ℉). The tape has a shelf life of 12 months and provides excellent adhesion strength (1200 gf/in) with a PET liner. It also offers low electrical resistance of XY-axis 0.015 Ω.
Specifications
Manufacturer
3M
Adhesive Type
Acrylic
Component
Electrical Tape
Maximum Operating Temperature (Fahrenheit)
250 °F
Maximum Operating Temperature (Celsius)
121 °C
Width (Metric)
500 mm
Sub Component
Conductive Adhesive Transfer Tape
Width (Imperial)
19.685 In
Length (Imperial)
32.808 Yd
Length (Metric)
30 M
Color
Gold
Features
XYZ-axis conductivity
Stiffer copper for improved workability
Thin profile
Low electrical resistance
High shielding performance
Excellent conformability and quick bonding
Good handling and workability
Great passive intermodulation (PIM) performance
Halogen free* and RoHS compliant*
