Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Code: 473371
3M 7100313409 - 3M Electrically Conductive Single-Sided Tape 1050TC-25, 100 mm x 10 m
Normally In Stock
3M Electrically Conductive Single-Sided Tape 1050TC-25, 100 mm x 10 m - 7100313409
Condition: New
CALL FOR LEAD TIMEMUST ORDER A MINIMUM OF $500 FROM 3M FOR PRODUCT TO SHIP
$468.91
Sale Price
$390.76
SOLD BY THE CASE (1 Case = 8 Roll)
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
3M 7100313409 - Conductive Adhesive Transfer Tape (CAT) 1050TC-25 is a gold-colored product designed for various applications such as camera modules, display chip on flex, EMI shields, and more. The tape has an overall width of 3.937 in (100 mm), overall length of 10.936 yd (10 m), and a total tape thickness without liner of 0.023 mm (0.906 mil). It is made of acrylic adhesive with a copper foil backing material. The CAT has a maximum operating temperature of 121 ℃ (250 ℉) and a minimum operating temperature of -40 ℃ (-40 ℉). With a shelf life of 12 months, it provides strong adhesion strength of 1200 gf/in and has an electrical resistance of XY-axis 0.015 Ω. The liner is made of PET material.
Specifications
Manufacturer
3M
Adhesive Type
Acrylic
Component
Electrical Tape
Maximum Operating Temperature (Fahrenheit)
250 °F
Maximum Operating Temperature (Celsius)
121 °C
Length (Metric)
10 M
Width (Metric)
100 mm
Sub Component
Conductive Adhesive Transfer Tape
Length (Imperial)
10.936 Yd
Width (Imperial)
3.937 In
Color
Gold
Features
XYZ-axis conductivity
Stiffer copper for improved workability
Thin profile
Low electrical resistance
High shielding performance
Excellent conformability and quick bonding
Good handling and workability
Great passive intermodulation (PIM) performance
Halogen free* and RoHS compliant*
Downloads
Code: 473371
3M 7100313409 - 3M Electrically Conductive Single-Sided Tape 1050TC-25, 100 mm x 10 m
$468.91
Sale Price
$390.76
SOLD BY THE CASE (1 Case = 8 Roll)
