Application: Designed to house electrical and electronic controls, instrumentation and components in indoor, outdoor and sanitary locations.For Details about the Design, Performance Expectations, Applications and Design Suggestions - See Design Considerations www.saginawcontrol.com/instman/considerations.pdf

0.075 In. stainless steel Type 304

Seams continuously welded and ground smooth

Flange trough collar around all sides of door opening

15 degree sloping top

Collar studs 3/8-16 provided for mounting optional panels

Mounting holes in back of the enclosure for wall mounting

Mounting hardware, sealing washers and hole plugs included

Stainless Steel Concealed hinges

Removable and interchangeable doors

Black quarter turn latches

Latches are opened or closed with a screwdriver (optional tamper resistant latches are available)

Removable print pocket furnished if height and width of enclosure is greater than 12 inches

Pour in place oil & water resistant gasket

Ground stud on door and body

Provision for Lifting Lugs will be included on enclosures with Height >48 In. and with Depth >16 In. The Lifting Lug assembly will be included with the enclosure bolt pack.
