Schneider Electric 9001KR9H13 Harmony Chromium plated metal Mushroom Non-Illuminated Modular Complete product
Normally In Stock
Code: 46285
Schneider Electric 9001KR9H13 Harmony Chromium plated metal Mushroom that is Non-Illuminated . This product is a Modular Complete product and.
Condition: New
Usually ships Same Day or Next Day$218.39
Sale Price
$181.99
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Schneider Electric 9001KR9H13 Harmony Chromium plated metal Non-Illuminated Mushroom Modular Complete product is made of high quality material and is designed to be simple and flexible.
Specifications
(Switching-Indication) Size
30 mm
(Switching-Indication) Illumination
Non-Illuminated
(Switching-Indication) Composition
Chromium Plated Metal
(Switching-Indication) NEMA Rating
NEMA 1
(Switching-Indication) NEMA Rating
NEMA 12
(Switching-Indication) NEMA Rating
NEMA 13
(Switching-Indication) NEMA Rating
NEMA 2
(Switching-Indication) NEMA Rating
NEMA 3
(Switching-Indication) NEMA Rating
NEMA 3R
(Switching-Indication) NEMA Rating
NEMA 4
(Switching-Indication) NEMA Rating
NEMA 6
Manufacturer
Schneider Electric
Component
Modular Push Button
Features
The 9001K push button line has a large variety of operators and accessories for heavy industry applications
These operators are used in the petrochemical, metallurgy, mining, oil and gas, wastewater treatment and automotive manufacturing industries and more
Type K operators have a die cast operator that mounts in a 1.18 inch round hole
This non-illuminated push pull push button operator has a metal ring nut
This operator has one 9001KA1 contact block
Contact block have a UL Type A600, UL Type Q600 and a 10A resistive VAC rating
The contacts in these contact blocks are double break direct acting
Contact blocks will accept up to two 12AWG to 24 AWG solid or stranded wires
The contact block terminals are protected to meeting VDE 0106 Part 100
This operator can be made illuminated by adding a light module
A push pull knob like the 9001R22, needs to be ordered separately for this operator
A variety of colors are available
When properly installed this opertor is UL listed for Types 1, 2, 3, 3R, 4, 6, 12 and 13 environments
This operator is UL Listed and CSA certified
\A comprehensive range of illuminated pushbuttons, pilot lights, emergency stop buttons, selector switches, joystick controllers and accessories to fit your needs.\,\The modular range of Ø 30mm metal control and signaling provides robust and reliable solutions for a wide range of heavy industry applications.\
