Phoenix Contact 1827567 PCB header SMC 1,5/16-GF-3,81
Normally In Stock
Code: 451164
Phoenix Contact 1827567 SMC 1,5/16-GF-3,81 - PCB header, 8 Amp, 3.81 mm Pitch, Tin -
Condition: New
Usually ships Within 1 Week$12.04
Sale Price
$10.03
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1827567 A PCB header with a nominal cross-sectional area of 1.5 mm2 has a green color and is rated for a maximum current of 8 A under a voltage of 160 V. The header features a Sn contact surface and uses pin connections with 16 potentials, each connected to one solder pin that spans the full length of 3.4 mm on the PCB. The headers are designed for wave soldering and have a linear pinning layout, making them suitable for mounting using a threaded flange. The standard packaging consists of cardboard.
Specifications
Connector Color
Green
Connector Amperage
8 Amp
Connector Material
Tin
Manufacturer
Phoenix Contact
Number of Connections
16
Number of Positions
16
Component
PCB
Sub Component
PCB Header
Connector Voltage
160 Volt
Connector Mounting Type
Wave Soldering
Connector Pitch
3.81 mm
Features
Well-known mounting principle allows worldwide use
Screwable flange for superior mechanical stability
Angled connection enables multi-row arrangement on the PCB
Maximum flexibility when it comes to device design – one header for connectors with different connection technologies
