Schneider Electric ZB4BA73133 Harmony 22 mm Rectangular Green and Red Chromium plated metal Multiple Push Buttons Projecting and Flush Modular Heads
Normally In Stock
Code: 44859
Schneider Electric ZB4BA73133 Harmony 22 mm Rectangular Green and Red Chromium plated metal Multiple Push Buttons that is with a Projecting and Flush profile. This product is a Modular Heads and and is IP 69 rated and UL 508 certified.
Condition: New
Usually ships Same Day or Next Day$104.20
Sale Price
$86.83
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Schneider Electric ZB4BA73133 Harmony 22 mm Rectangular Green and Red Chromium plated metal Multiple Push Buttons Modular Heads with a Projecting and Flush profile is made of high quality material and is designed to be simple and flexible. Has Spring return functionality. This product is IP 69 and UL 508 rated and is Marked Green ''right arrow'' - green ''left arrow'' - red ''STOP''.
Specifications
(Switching-Indication) Operation
Spring Return
(Switching-Indication) Composition
Chromium Plated Metal
(Switching-Indication) NEMA Rating
NEMA 13
(Switching-Indication) Size
22 mm
(Switching-Indication) Color
Green
(Switching-Indication) Color
Red
(Switching-Indication) UL Rating
UL 508
(Switching-Indication) Shape
Rectangular
(Switching-Indication) NEMA Rating
NEMA 4X
(Switching-Indication) IP Rating
IP 69
Sub Component
Head
Manufacturer
Schneider Electric
Component
Accessories
Features
This Harmony XB4, triple head has 1 red and 2 green buttons, operates with a spring return / impulse mechanism
It is marked with \left arrow\, \STOP\ and \right arrow\ symbols
This 3-function head provides a complete 3 button interface to your machines with a single panel cut-out
It is easily installed into a standard 22mm diameter cut-outs and assembled with a collar and contact blocks to fulfill a large variety of functions
It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66 and IP69K
It has a metal bezel, this makes it Ideal for applications requiring high impact and vibration resistance
It is designed to fit in a standard 22mm cutout, ensuring compatibility when installing in pre-existing machinery
Its wide range of operating temperatures from -25°C to 70°C allows versatility in usage of product.
