Eaton PDK23K0020TFFJ - Direct Current Circuit Breaker 3P, 20 Amp, 600 VDC, 2 Frame
Normally In Stock
Code: 439187
Eaton PDK23K0020TFFJ - Direct Current, PDK2, 3P, 20A, 50kA/600VDC, FXFX Thermal Magnetic Trip Unit, STD LINE/LOAD TERM
Condition: New
Usually ships Same Day or Next Day$706.09
Sale Price
$588.41
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Eaton PDK23K0020TFFJ - Eaton's Power Defense Direct Current Circuit Breakers are designed for the growing prevalence of direct current (DC) systems in various applications, such as UPS battery supply circuits, solar installations, electric vehicle charging, and industrial distribution. They offer current ratings from 25 to 3000 A and support voltage levels up to 600 Vdc, accommodating a wide range of performance needs. These DC breakers are CSA and UL 489 listed, suitable for both ungrounded and select grounded applications, and can be used with the same accessories as their standard Power Defense counterparts, ensuring reliable and flexible circuit protection solutions. - 5" x 5" x 7.5" (HxWxD)
Specifications
Amperage (Molded Case Breaker)
20 Amp
Poles (Molded Case Breaker)
Three Pole
UL Listing (Molded Case Breaker)
UL 489
Interrupt Rating (Molded Case Breaker)
50 Ka 480 Volt
Manufacturer
Eaton
Maximum Voltage (Molded Case Breaker)
600 VDC
Interrupt Rating (Molded Case Breaker)
35 Ka 600 Volt
Frame Type (Molded Case Breaker)
2 Frame
Component
Direct Current Circuit Breaker
Trip Unit Type
T-M (Fxd-Fxd) TU
Features
Globally accepted platform in a number of industry standards including UL®, CSA,IEC, and CCC.
Power Xpert Release trip units offer features such as Breaker Health, multiple Load Alarms, and Ground Fault Alarm to help avoid costly downtime through predictive and preventative maintenance.
Arcflash Reduction Maintenance System helps to reduce arc flash incident energy levels, thereby reducing PPE requirements and minimizing risk while improving personnel safety and productivity.
The PXR trip units provide an intuitive user interface that allows you to easily view and adjust breaker settings and system performance.
Embedded communications and metering help to reduce cost by eliminating the need for separate communication components and associated wiring.
Field installable components and trip units minimize the amount of inventory while enabling the user almost infinite options to customize the breaker to the application and their specification.
