Phoenix Contact 3212444 Double-level terminal block PTTB 1,5/S/2P BK
Normally In Stock
Code: 42441
PTTB 1,5/S/2P BK Phoenix Contact 3212444 Double-level Terminal Block - PTTB 1,5/S/2P BK Push-In Connection 1 Level 3.5 mm with 4 Connections. Not Grounded, Not Fused Black. 500 V, 16 A max rating.
Condition: New
Usually Ships Same day or Next Day$3.14
Sale Price
$2.62
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 3212444 A double-level terminal block features a plug-based connection system where current and voltage are defined by the specific plug used, with standard specifications including a nominal voltage of 500 V and a maximum nominal current of 16 A. The connection method employs push-in or plug connections, applied to both the first and second levels of the terminal block, with a rated cross-sectional area ranging from 0.14 mm2 to 1.5 mm2. Mounting is typically done using the NS 35/7,5 or NS 35/15 type, with a distinctive black coloration.
Specifications
Terminal Block Indication
No Indicator
Terminal Block Voltage Rating
500 Volt
Terminal Block Fused
Not Fused
Terminal Block Number of Connections
4
Terminal Block Width
3.5 mm
Terminal Block Number of Levels
2
Terminal Block Grounded
Not Grounded
Terminal Block Min Wire Size
26
Terminal Block Connection Method
Push-In Connection
Terminal Block Max Wire Size
16
Terminal Block Component Color
Black
Terminal Block Connection Method
Plug Connection
Terminal Block Amperage
16 Amp
Component
Terminal Block
Manufacturer
Phoenix Contact
Sub Component
Plug-In Terminal Block
Sub Component
Double-Level Terminal Block
Features
The Push-in connection terminal blocks are characterized by the system features of the CLIPLINE complete system and by easy and tool-free wiring of conductors with ferrules or solid conductors
The compact design and front connection enable wiring in a confined space
In addition to the testing option in the double function shaft, all terminal blocks provide an additional test pick-off
Tested for railway applications
