Code: 41750
Phoenix Contact 3213949 Installation protective conductor terminal block PTI 2,5-PE/L/L
Normally In Stock
PTI 2,5-PE/L/L Phoenix Contact 3213949 Installation ground Terminal Block - PTI 2,5-PE/L/L Push-In Connection 1 Level 5.2 mm with 2 Connections. Grounded, Not Fused Gray. 400 V, 30 A max rating.
Condition: New
Usually Ships Same day or Next Day$5.89
Sale Price
$4.91
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 3213949 The installation protective conductor terminal block is rated for 400V and 24A nominal current, featuring a push-in connection system with three levels of connection and various cross-section ratings ranging from 0.14mm2 to 4mm2. The mounting type includes NS35/7.5 and NS35/15 standards, while the color coding is gray.
Specifications
Terminal Block Indication
No Indicator
Terminal Block Voltage Rating
400 Volt
Terminal Block Fused
Not Fused
Terminal Block Width
5.2 mm
Terminal Block Number of Levels
3
Terminal Block Number of Connections
5
Terminal Block Component Color
Gray
Terminal Block Max Wire Size
12
Terminal Block Grounded
Grounded
Terminal Block Min Wire Size
26
Terminal Block Connection Method
Push-In Connection
Terminal Block Amperage
24 Amp
Component
Terminal Block
Manufacturer
Phoenix Contact
Sub Component
Ground Terminal Block
Sub Component
Installation Ground Terminal Block
Features
Double function shafts on all levels
