ABB AS16-30-32S-26 - 230 VAC, 15.7 Amp, 3P, 50/60 Hz
Normally In Stock
Code: 414651
ABB AS16-30-32S-26 - AC Contactor - 230 VAC - 50/60 Hz - 15.7 Amp - 3 NO - Three Pole - 0.75-2 HP @ 220-240 VAC 1 Phase, 3-10 HP @ 208-600 VAC 3 Phase - Spring Terminals
Condition: New
Usually ships Same Day or Next Day$380.20
Sale Price
$316.83
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
ABB AS16-30-32S-26 - AS16 contactors are mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC or 220 V DC. They are mainly used for controlling 3-phase motors, non-inductive or slightly inductive loads. The AS..S contactors are the spring terminal version of the AS... range. The AS... series 2-stack 3-pole contactors are of the block type design. - Main poles and auxiliary contact blocks: 1st stack with 3 main poles and 1 N.O. built-in auxiliary contact, with a non-removable front-mounted 2 N.O. + 2 N.C. auxiliary contact block (mechanically-linked auxiliary contacts compliant with Annex L of IEC 60947-5-1 including the "Mechanically Linked" symbol on the contactor side. N.C. mirror contacts compliant with Annex F of IEC 60947-4-1) - Control circuit: AC operated with laminated magnet circuit - Accessories: a wide range of accessories is available.
Specifications
Starter Frequency
60 Hz
Starter HP
10 HP @ 480 VAC 3 Phase
Starter HP
3 HP @ 208 VAC 3 Phase
Starter Coil Voltage
230 VAC
Starter HP
2 HP @ 240 VAC 1 Phase
Starter HP
3 HP @ 200 VAC 3 Phase
Starter Frequency
50 Hz
Starter Poles
Three Pole
Starter Auxiliary Contacts
3 NO
Manufacturer
ABB
Component
AC Contactor
Starter HP
5 HP @ 220 VAC 3 Phase
Starter HP
5 HP @ 240 VAC 3 Phase
Starter HP
10 HP @ 440 VAC 3 Phase
Starter HP
10 HP @ 550 VAC 3 Phase
Starter HP
10 HP @ 600 VAC 3 Phase
Starter HP
0.75 HP @ 220 VAC 1 Phase
Starter Amperage
15.7 Amp
