Code: 40805
Phoenix Contact 3004168 Test disconnect terminal block UK 5-HESI-T OG
Normally In Stock
UK 5-HESI-T OG Phoenix Contact 3004168 Test disconnect Terminal Block - UK 5-HESI-T OG - Test disconnect Terminal Block, nom. voltage: 500 V, nominal current: 6.3 A,
Condition: New
Usually Ships Same day or Next Day$17.47
Sale Price
$14.56
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 3004168 For a test disconnect terminal block, use marking material with 8.2 mm pitch and follow specific voltage (800 V) and current (6.3 A) guidelines for connections, which involve screw connections with rated cross sections ranging from 1 mm² to 4 mm², suitable mounting options include NS 35/7.5, NS 35/15, and NS 32, and the terminals should be colored orange.
Specifications
Terminal Block Indication
No Indicator
Terminal Block Voltage Rating
800 Volt
Terminal Block Fused
Fused
Terminal Block Width
8.2 mm
Terminal Block Number of Levels
1
Terminal Block Number of Connections
2
Terminal Block Connection Method
Screw Connection
Terminal Block Grounded
Not Grounded
Terminal Block Max Wire Size
12
Terminal Block Min Wire Size
24
Terminal Block Component Color
Orange
Terminal Block Disconnect
Removable Disconnect
Component
Terminal Block
Manufacturer
Phoenix Contact
Terminal Block Amperage
6.3 Amp
Sub Component
Disconnect Terminal Block
Sub Component
Test Disconnect Terminal Block
Features
High-level functionality with up to six universal function shafts for potential distribution or test purposes
Modular design for current transformer and measuring transducer switching with plug-in transformer terminal blocks
Reliable protection of connected current transformers and measuring transducers with plug versions with integrated leading short-circuit contact
Simple and functional design with feed-through terminal blocks and PE terminal blocks of the same shape
Reliable contacting and latching of the section disconnector in the respective switching state
Clear identification of the switching states
Downloads
Phoenix 3004168 CAD data International.dxfPhoenix 3004168 CAD data International.pdfPhoenix 3004168 CAD data International.stpPhoenix 3004168 Manufacturers declaration English.pdfPhoenix 3004168 Manufacturers declaration International.pdfPhoenix 3004168 Safety note English.pdfPhoenix 3004168 Tender Text English.zip
