Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Code: 40797
Phoenix Contact 1044423 Fuse modular terminal block UT 4-L/HESI (5X20) GY
Normally In Stock
UT 4-L/HESI (5X20) GY Phoenix Contact 1044423 Fuse modular Terminal Block - UT 4-L/HESI (5X20) GY - fuse type: Glass Screw Connection 2 Level 6.2 mm with 4 Connections. Not Grounded, Fused Gray. 500 Volt, 28 Amp max rating.
Condition: New
Usually Ships Same day or Next Day$10.01
Sale Price
$8.34
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 1044423 The fuse terminal block is a modular unit with various specifications. It has glass or ceramic fuses in the G type configuration, measuring 5 x 20mm and rated for 250V nominal voltage. The thermal continuous current capacity is 28A, and it features screw connections with a rated cross section of 4mm2. The available cross sections range from 0.14 to 6mm2, also using screw connections. The terminal block can be mounted using the NS35/7,5 or NS35/15 mounting types, and its body is typically gray in color.
Specifications
Terminal Block Indication
No Indicator
Terminal Block Voltage Rating
500 Volt
Terminal Block Fused
Fused
Terminal Block Width
6.2 mm
Terminal Block Number of Connections
4
Terminal Block Number of Levels
2
Terminal Block Component Color
Gray
Terminal Block Connection Method
Screw Connection
Terminal Block Grounded
Not Grounded
Terminal Block Max Wire Size
10
Terminal Block Min Wire Size
26
Terminal Block Fuse Type
G - 5 X 20
Component
Terminal Block
Manufacturer
Phoenix Contact
Terminal Block Amperage
28 Amp
Sub Component
Fuse Terminal Block
Sub Component
Fuse Modular Terminal Block
Features
Comprehensive product range for cartridge fuse-links, automotive flange fuses, and thermal device circuit breaker plugs
Easy potential distribution thanks to continuous function shafts
Convenient testing of fuses with test points on both sides
Quick identification of faulty fuses and fuse holders regardless of the current direction thanks to an LED status indicator
Easily accessible fuse-links are easy to replace
Same shape as the feed-through, knife, and disconnect terminal blocks
Downloads
Phoenix 1044423 Certification English.pdfPhoenix 1044423 Certification International.pdfPhoenix 1044423 Manufacturers declaration English.pdfPhoenix 1044423 Manufacturers declaration International-2.pdfPhoenix 1044423 Manufacturers declaration International.pdfPhoenix 1044423 Safety note English.pdfPhoenix 1044423 Tender Text English.zipPhoenix 1044423 User instructions for the Ex Area International.pdfproduct drawing.dxfsimplified 3d model of the item.stp
