Phoenix Contact 1086499 High-current terminal block UBAL 150 BU
Normally In Stock
Code: 40784
UBAL 150 BU Phoenix Contact 1086499 High-current Terminal Block - UBAL 150 BU Screw Connection 1 Level 30.5 mm with . Not Grounded, Not Fused Blue. 1000 Volt, 290 Amp max rating.
Condition: New
Usually Ships Same day or Next Day$39.16
Sale Price
$32.63
MUST BUY IN PACKS OF10
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 1086499 A high-current terminal block features a nominal voltage of 1000 V and a maximum current capacity of 290 A, with two connections and one position for mounting. The connection method is screw-based, with rated cross-sectional areas ranging from 35 mm2 to 150 mm2. These terminal blocks are typically mounted using the NS 35/15 or NS 35/7.5 mounting type, and have a blue color.
Specifications
Terminal Block Indication
No Indicator
Terminal Block Voltage Rating
1000 Volt
Terminal Block Fused
Not Fused
Terminal Block Width
30.5 mm
Terminal Block Number of Levels
1
Terminal Block Number of Connections
2
Terminal Block Component Color
Blue
Terminal Block Connection Method
Screw Connection
Terminal Block Grounded
Not Grounded
Terminal Block Min Wire Size
2
Terminal Block Max Wire Size
300
Component
Terminal Block
Manufacturer
Phoenix Contact
Terminal Block Amperage
290 Amp
Sub Component
Feed-Through Terminal Block
Sub Component
High-Current Terminal Block
Features
Tailor-made screw connection for multi-stranded aluminum conductors and copper wires
Maintenance-free terminal points that are greased beforehand simplify the connection of aluminum conductors
Extremely robust housing made from fiberglass-reinforced polyamide with V0 approval
The special design of the UBAL enables the simultaneous connection of aluminum and copper conductors in various connections
