Code: 40571
Phoenix Contact 3100208 Knife-disconnect terminal block MTK MIT SPERRE
Normally In Stock
MTK MIT SPERRE Phoenix Contact 3100208 MTK MIT SPERRE Knife disconnect Terminal Block, nom. voltage: 400 V, nominal current: 16 A,
Condition: New
Usually Ships Same day or Next Day$12.02
Sale Price
$10.02
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 3100208 The terminal block features a knife-disconnect system with a nominal voltage of 400 V and a maximum current capacity of 16 A. The connection method utilizes screw connections and has a rated cross-sectional area of 2.5 mm². The actual cross-section range is between 0.2 mm² to 4 mm², allowing for various wiring configurations. Mounting options include NS 35/7.5, NS 35/15, and NS 32, with the device being gray in color.
Specifications
Terminal Block Indication
No Indicator
Terminal Block Voltage Rating
400 Volt
Terminal Block Disconnect
Knife Disconnect
Terminal Block Fused
Not Fused
Terminal Block Width
5.2 mm
Terminal Block Number of Levels
1
Terminal Block Number of Connections
2
Terminal Block Component Color
Gray
Terminal Block Connection Method
Screw Connection
Terminal Block Grounded
Not Grounded
Terminal Block Max Wire Size
12
Terminal Block Min Wire Size
24
Terminal Block Amperage
16 Amp
Component
Terminal Block
Manufacturer
Phoenix Contact
Sub Component
Disconnect Terminal Block
Sub Component
Knife Disconnect Terminal Block
Features
Convenient separation of circuits with a lever-type disconnect knife, isolating plug, or rotary contact
User-friendly current measurement via the testing option on either side of the disconnect point
Safe operation, as the disconnect lever is latched in the end positions
Clear identification of the disconnect point with color marking
Individual assembly with disconnect element, fuse plug, component connector, and feed-through connector
Downloads
Phoenix 3100208 CAD data International.dxfPhoenix 3100208 CAD data International.pdfPhoenix 3100208 CAD data International.stpPhoenix 3100208 Manufacturers declaration English.pdfPhoenix 3100208 Manufacturers declaration International-2.pdfPhoenix 3100208 Manufacturers declaration International.pdfPhoenix 3100208 Safety note English.pdfPhoenix 3100208 Tender Text English.zip
