Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Code: 40564
Phoenix Contact 2775223 Knife-disconnect terminal block UDK 4-MTK-P/P BU
Normally In Stock
UDK 4-MTK-P/P BU Phoenix Contact 2775223 UDK 4-MTK-P/P BU Knife disconnect Terminal Block, With test socket screws for insertion of test plugs, nom. voltage: 630 V, nominal current: 16 A
Condition: New
Usually Ships Same day or Next Day$13.43
Sale Price
$11.19
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2775223 The knife-disconnect terminal block features test socket screws for inserting test plugs and is designed to operate at a nominal voltage of 630V with a maximum current capacity of 16A. The connection method is screw-based, allowing for rated cross sections ranging from 0.2mm² to 6mm². Mounting options include NS 35/7.5, NS 35/15, and NS 32, while the terminal block itself has a blue coloration.
Specifications
Terminal Block Indication
No Indicator
Terminal Block Disconnect
Knife Disconnect
Terminal Block Voltage Rating
630 Volt
Terminal Block Fused
Not Fused
Terminal Block Width
6.2 mm
Terminal Block Number of Levels
1
Terminal Block Number of Connections
4
Terminal Block Component Color
Blue
Terminal Block Connection Method
Screw Connection
Terminal Block Grounded
Not Grounded
Terminal Block Min Wire Size
24
Terminal Block Max Wire Size
10
Terminal Block Amperage
16 Amp
Component
Terminal Block
Manufacturer
Phoenix Contact
Sub Component
Disconnect Terminal Block
Sub Component
Knife Disconnect Terminal Block
Features
Closed housing of double-level terminal blocks
Space-saving design just 6.2 mm wide
User-friendly disconnect knife operation
Downloads
Phoenix 2775223 CAD data International.dxfPhoenix 2775223 CAD data International.pdfPhoenix 2775223 CAD data International.stpPhoenix 2775223 Manufacturers declaration English.pdfPhoenix 2775223 Manufacturers declaration International-2.pdfPhoenix 2775223 Manufacturers declaration International-3.pdfPhoenix 2775223 Manufacturers declaration International.pdfPhoenix 2775223 Safety note English.pdfPhoenix 2775223 Tender Text English.zip
