Phoenix Contact 2904602 Power supply QUINT4-PS/1AC/24DC/20
Normally In Stock
Code: 36893
QUINT4-PS/1AC/24DC/20 Phoenix Contact 2904602 Power Supply 24V 20A QUINT
Condition: New
Usually ships Same Day or Next Day$521.54
Sale Price
$434.62
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2904602 A primary-switched quint power supply unit offers flexibility in selecting the desired output voltage characteristics, features selective fuse breaking for added safety, and integrates an NFC interface for convenient connection options. The device accepts a single-phase AC input and supplies 24V DC with a maximum current rating of 20A.
Specifications
Power Supply Type
Switching
Power Supply Mounting
Din Rail Mount
Power Supply Number of Outputs
Single Output
Power Supply Watts
480 Watt
Power Supply Voltage Output
24 VDC
Power Supply Housing
Enclosed
Power Supply Amperage Output
20 Amp
Component
Power Supply
Manufacturer
Phoenix Contact
Line
QUINT
Power Supply Amperage Output Range
16-20 Amp
Power Supply Voltage Input Range
100 VAC - 240 VAC
Features
Easy system extension thanks to static boost
starting of difficult loads thanks to dynamic boost
Preventive function monitoring indicates critical operating states before errors occur
Signaling thresholds and characteristic curves that can be adjusted via NFC maximize system availability
SFB technology trips standard circuit breakers selectively, loads that are connected in parallel continue working
High degree of immunity, thanks to integrated gas-filled surge arrester and mains failure bridging time of more than 20 milliseconds
Robust design thanks to metal housing and wide temperature range from -40°C to +70°C
Worldwide use thanks to the wide range input and international approval package
Downloads
Phoenix 2904602 CAD data International.dxfPhoenix 2904602 CAD data International.pdfPhoenix 2904602 CAD data International.stpPhoenix 2904602 Data Sheet English.pdfPhoenix 2904602 Manual English.pdfPhoenix 2904602 Manufacturers declaration English.pdfPhoenix 2904602 Manufacturers declaration International-2.pdfPhoenix 2904602 Manufacturers declaration International.pdfPhoenix 2904602 Software International.zipPhoenix 2904602 Tender Text English.zipPhoenix 2904602 Various English.pdfPhoenix 2904602 Various English.wmv
