Code: 358260
Eaton E52Q-DL15UAE01 Inductive Proximity Sensor
Normally In Stock
Eaton E52Q-DL15UAE01 - E52 Series, 0 - 15 mm Sensing Range - 300 mA at 48 VDC - PPS housing - Power: green,Output: red
Condition: New
Usually ships Same Day or Next Day$233.41
Sale Price
$194.51
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Eaton E52Q-DL15UAE01 - E52 Cube Style Inductive Proximity Sensor, Sensor dist.: 15 mm, PPS Housing enclosure, 300 mA max DC, Complementary NPN/PNP Auto-configure, 4 Pin Mini Connector, 6-48 Vdc input, < 2% accuracy
Specifications
Component
Inductive Proximity Sensor
(Instrument-Sensor) NEMA Protection
NEMA 4X
(Instrument-Sensor) IP Protection
IP67
(Instrument-Sensor) IP Protection
IP68
(Instrument-Sensor) Type of Operator
NPN
(Instrument-Sensor) Type of Operator
PNP
(Instrument-Sensor) NEMA Protection
NEMA 4
(Instrument-Sensor) NEMA Protection
NEMA 13
(Instrument-Sensor) NEMA Protection
NEMA 6P
(Instrument-Sensor) NEMA Protection
NEMA 6
(Instrument-Sensor) NEMA Protection
NEMA 12
Manufacturer
Eaton
(Instrument-Sensor) Span
0 - 15 mm
(Instrument-Sensor) Temperature Range
-40 °F - 158 °F
(Instrument-Sensor) Supply Voltage
6-48 VDC
(Instrument-Sensor) Contact Rating
300 Ma At 48 VDC
(Instrument-Sensor) Connection Type
4 Pin Mini Connector
(Instrument-Sensor) Type
Inductive Proximity Cube Sensor
Features
Small, low-profile design for use in space restrictive applications
Three-wire DC operation
Choose from a variety of sizes, and side or end sensing configurations
Output indicator included on all models
Epoxy filled cavities stop fluids from contacting any electrical component
Convenient mounting holes integrated into each sensor housing
