Code: 329194
Eaton CCV2200X Main Breaker, 240 Max Volt, 200 Amp, Two Pole
Normally In Stock
Eaton CCV2200X - CCV Type - 240 VAC - 200 Amp - Two Pole
Condition: New
CALL FOR LEAD TIME$619.94
Sale Price
$516.62
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Eaton CCV2200X - Tenant main circuit breaker,200 A,10 kAIC,Two-pole,120/240 V,#2/0 AWG-300 kcmil Cu/Al,CCV,Type ECC unit enclosures,Load side terminals
Specifications
Manufacturer
Eaton
Component
Main Circuit Breaker
Poles
Two Pole
Interrupt Rating
10 Ka
Amperage
200 Amp
Maximum Voltage
240 VAC
UL Listing
UL 489
Features
10-100 kAIC for range of interrupting capacities
Oversized 300 MCM load-side lugs on most main breakers
Easily interchangeable for custom solutions
