Phoenix Contact 1313300 Device connector front mounting PRC 20/3-C1-FT25-FS2,5
Normally In Stock
Code: 309136
Phoenix Contact 1313300 - Device connector front mounting - 3 Positions - Black - 25 Amp - IP66 - Screw Connection
Condition: New
Usually ships Same Day or Next Day$12.80
Sale Price
$10.67
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1313300 A device connector front mounted with a range of articles, including the PRC 20 model, features a black color and three positions. The conductor cross sections can vary from as little as 0.5 mm2 to as much as 2.5 mm2, while it is rated for 400 V and 25 A of current. This connector employs a screw connection method with socket contacts, allowing for either manual or tool-assisted release options. It operates within the AC scope.
Specifications
Connector Color
Black
Connector Amperage
25 Amp
Connector Material
PPE
Connector protection
IP66
Component
Connector
Manufacturer
Phoenix Contact
Number of Positions
3
Sub Component
Device Connector-Front Mounting
Features
More space on the device front with current transmission up to 20 A in a minimum amount of space
Duo-Unlock technology for greater flexibility during installation and maintenance
Reliable use under extreme ambient conditions with high degrees of protection and impact resistance
Simple handling with proven crimp or screw connection technology
Mechanical and color coding for quick and error-free startup
