Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Phoenix Contact 1308660 Connector PRC 20/5-C1-FC-MS2,5 6-14
Normally In Stock
Code: 309131
Phoenix Contact 1308660 - Connector - 5 Positions - Black - 20 Amp - IP66 - Screw Connection
Condition: New
Usually ships Same Day or Next Day$16.13
Sale Price
$13.44
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1308660 This connector has various specifications including a range of articles available from the PRC 20 standard, black and red colors, five positions, conductor cross sections ranging from 0.5 to 2.5 mm2, rated voltages and currents up to 400 V and 20 A respectively, screw connection method with pin contact type, cable diameters between 8-14 mm, and has a setting option for release that can be done with or without a tool, catering to AC connections.
Specifications
Connector Color
Black
Connector Amperage
20 Amp
Connector Material
PPE
Connector protection
IP66
Component
Connector
Manufacturer
Phoenix Contact
Number of Positions
5
Sub Component
Installation Connector
Features
More space on the device front with current transmission up to 20 A in a minimum amount of space
Duo-Unlock technology for greater flexibility during installation and maintenance
Reliable use under extreme ambient conditions with high degrees of protection and impact resistance
Simple handling with proven crimp or screw connection technology
Mechanical and color coding for quick and error-free startup

Code: 309131
Phoenix Contact 1308660 Connector PRC 20/5-C1-FC-MS2,5 6-14
$16.13
Sale Price
$13.44
