Phoenix Contact 1336395 Disconnect terminal block PT 2,5-L/L/L/TG
Normally In Stock
Code: 301606
PT 2,5-L/L/L/TG Phoenix Contact 1336395 PT 2,5-L/L/L/TG Disconnect terminal block
Condition: New
Usually Ships Same day or Next Day$14.12
Sale Price
$11.77
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1336395 The terminal block is rated for 500V and has a maximum continuous current of 18A. It uses push-in connections with a cross-sectional area ranging from 0.14mm^2 to 4mm^2. Mounting options include NS 35/7,5 and NS 35/15, and the terminal block is typically gray in color.
Specifications
Terminal Block Voltage Rating
500 Volt
Terminal Block Number of Connections
8
Terminal Block Number of Levels
2
Terminal Block Component Color
Gray
Terminal Block Connection Method
Push-In Connection
Jumper Number of Positions
4
Component
Terminal Block
Manufacturer
Phoenix Contact
Terminal Block Amperage
18 Amp
Sub Component
Disconnect Terminal Block
Features
Convenient separation of circuits with a lever-type disconnect knife, isolating plug, or rotary contact
User-friendly current measurement via the testing option on either side of the disconnect point
Safe operation, as the disconnect lever is latched in the end positions
Clear identification of the disconnect point with color marking
Individual assembly with disconnect element, fuse plug, component connector, and feed-through connector
