Eaton CHUJGJGJGP Unmetered Power Outlet Panel
Normally In Stock
Code: 298892
Eaton CHUENENS - Pedestal Mounted - 4 Circuits - CB Position 1: 20A, GFI, 125V - CB Position 2: 20A, GFI, 125V - CB Position 3: 20A, GFI, 125V - Receptable Center: NEMA L5-20R - Left: NEMA L5-20R - Right: NEMA L5-20R
Condition: New
Usually ships Same Day or Next Day$2542.34
Sale Price
$2118.62
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
CHUJGJGJGP
• Pedestal mount:User mounts with an underground pedestal extension or pad-mounting bracket. UNDERGROUND PEDESTAL EXTENSION AND PADMOUNTING BRACKET ARE SOLD SEPARATELY
• 100 percent galvanized steel with baked-on polyester powder coating
• GFI circuit breakers (single- and two-pole) available through 50 A
• One-piece case back for metered and unmetered panels
• Removable upper deadfront cover for easy incoming wire connections to breaker terminals
• Door swings up when opening and allows cords to remain connected when closed
• Unique steel barrier prevents unauthorized operation of breakers when door is closed and padlocked
• Lower deadfront cover can be removed for easy routing of incoming wires or receptacle changeouts
• Padlock provisions to prevent unauthorized entry
• Loop-feed lug assembly with 350 kcmil lugs included as standard
• Pad-mounted bracket option also available
• Pedestal extension available for underground services
• Utility grade metering available for construction site or RV park applications
• NEMA 3R construction for rainproof installation
Specifications
Manufacturer
Eaton
Metering Status
Unmetered
Circuits
4
Breaker Max Voltage
125 VAC
Breaker Amp Rating 2
20 Amp
Breaker Amp Rating 3
20 Amp
Breaker Amp Rating 1
20 Amp
Breaker Type 1
GFI
Breaker Type 2
GFI
Breaker Type 3
GFI
Mounting
Pedestal
Receptable Center
NEMA L5-20R
Receptable Right
NEMA L5-20R
Receptable Left
NEMA L5-20R
Component
Power Pedestal
Features
Power outlet panels (POP) provide safe, reliable temporary power for construction sites.
Durable, long-lasting units are available as metered or unmetered and can be mounted at the surface, on a pedestal, or in a back-to-back configuration.
