Eaton S801+T18N3S Soft Starter - 180 Amp
Normally In Stock
Code: 294758
Eaton S801+T18N3S Soft Starter - 180 Amp 240 VAC
Condition: New
Usually ships Same Day or Next Day$7138.56
Sale Price
$5948.80
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Eaton S801+T18N3S - 180 A, T-frame, Three-pole, 24 V power, 200-600 V operating voltage, 47-63 Hz, 1-2 conductors, #5 AWG to 500 kcmil wire, 120 Vdc, 240 Vac, CIM, Three-phase motors, Modbus RTU, NEMA 0, LCD disp, -30°C to -50°C
Specifications
Component
Soft Starter
Manufacturer
Eaton
Starter Amperage
180 Amp
Features
Unique soft stopping pump control option provides a smooth transition for stopping a motor and eliminates the “water-hammer” effect that can damage pipes, valves and pumps
Advanced protective and diagnostic features using sophisticated algorithms that model motor heating. This results in fewer nuisance trips and reduced downtime
Compact size allows easy retrofits of existing motor control centers or enclosures, and saves the expense of replacing the existing structure or adding a new one to house a soft starter
Easy- to-use Digital Interface Module (DIM) allows the user to configure the device, read system parameters and monitor system values
Built-in overload (in ranges from 11–1000A) and run bypass contactor make installation and setup quick and easy
Reduces inrush current for a more stable power grid and can lower peak demand charges
Remote control and monitoring with our PC app through Power Xpert InControl
