Eaton AN13GN0A5E045 NEMA Non-Reversing Starter 45 Amp 110 Max Volt
Normally In Stock
Code: 293545
Eaton AN13GN0A5E045 - Non-Reversing - 45 Amp - 110 Max Volt - Open - 50 Hz/60 Hz - 6.3" X 1.77" X 5.5" (HxWxD)
Condition: New
Usually ships Same Day or Next Day$1755.48
Sale Price
$1462.90
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Eaton AN13GN0A5E045 - Space-Saving NEMA Starter, Full voltage non-reversing, XTOE electronic overload relay, NEMA Size 2 open enclosure - 45 A, Horizontal mounting, 120/60 or 110/50 coil voltage, C440 standard feature set - 9–45 A
Specifications
Starter Enclosure Type
Open
Starter NEMA Size
2
Starter Frequency
60 Hz
Starter Coil Voltage
110 VAC
Starter Frequency
50 Hz
Starter Reversing Capability
Non-Reversing
Starter Amperage
45 Amp
Manufacturer
Eaton
Component
NEMA Non-Reversing Starter
Starter Maximum Voltage
120 VAC
Features
Designed to meet or exceed NEMA, UL, CSA, VDE, BS and other international standards and listings
Adjustable bimetallic ambient compensated overload relays with interchangeable heater packs—available in three basic sizes, covering applications up to 900 hp—reducing the number of different contactor/overload relay combinations that have to be stocked. Fixed heater overloads are optional
Electronic overload relay (C440) available as a standalone unit and assembled with Freedom contactor
Horizontal or vertical mounting on upright panel for Freedom application
Screw type power terminals have captive, backed-out self-lifting pressure plates with ± screws—reduced wiring time
Accessible terminals for easy wiring. Optional fingerproof shields available to prevent electrical shock
A full line of snap-on accessories—top and side mounted auxiliary contacts, solid-state and pneumatic timers
Straight-through wiring— line lugs at top, load lugs at bottom
Top located coil terminals convenient and readily accessible. 45 mm contactor magnet coils have three terminals, permitting either top or diagonal wiring—easy to replace European or U.S. style starters or contactors without changing wiring layout
Sized based on standard NEMA classifications
Easy coil change and inspectable/replaceable contacts
Available in open and NEMA Type 1, 3R, 4/4X and 12 enclosures
