Designed to meet or exceed NEMA, UL, CSA, VDE, BS and other international standards and listings

Adjustable bimetallic ambient compensated overload relays with interchangeable heater packs—available in three basic sizes, covering applications up to 900 hp—reducing the number of different contactor/overload relay combinations that have to be stocked. Fixed heater overloads are optional

Electronic overload relay (C440) available as a standalone unit and assembled with Freedom contactor

Horizontal or vertical mounting on upright panel for Freedom application

Screw type power terminals have captive, backed-out self-lifting pressure plates with ± screws—reduced wiring time

Accessible terminals for easy wiring. Optional fingerproof shields available to prevent electrical shock

A full line of snap-on accessories—top and side mounted auxiliary contacts, solid-state and pneumatic timers

Straight-through wiring— line lugs at top, load lugs at bottom

Top located coil terminals convenient and readily accessible. 45 mm contactor magnet coils have three terminals, permitting either top or diagonal wiring—easy to replace European or U.S. style starters or contactors without changing wiring layout

Sized based on standard NEMA classifications

Easy coil change and inspectable/replaceable contacts

Available in open and NEMA Type 1, 3R, 4/4X and 12 enclosures
