Eaton ECC03C1HBA Electrically Held Lighting Contactor - 30 Amp, 277 Max Volt
Normally In Stock
Code: 285125
Eaton ECC03C1HBA - Twelve Pole - 30 Amp - 277 Max Volt - NEMA 1 - C30CN Series - 12.6" x 9.25" x 12.01" (HxWxD)
Condition: New
Usually ships Same Day or Next Day$3428.21
Sale Price
$2856.84
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Eaton ECC03C1HBA - 30 A, 277 V/60 Hz, 30 A, NEMA 1, Painted steel, 12-pole, Electrically held, C30CN Series, Non-combination electrically and mechanically held
Specifications
Starter Frequency
60 Hz
Starter Enclosure Type
NEMA 1
Starter Coil Voltage
277 VAC
Component
Lighting Contactor
Starter Amperage
30 Amp
Starter Poles
Twelve Pole
Manufacturer
Eaton
Sub Component
Electrically Held
Sub Component
Mechanically Held
Starter Class
C30CN
Features
30 A power pole rating
Configurable up to 12 poles maximum
Low magnetic noise results in quiet operation
Power poles latch easily onto the base, and designating them as NO or NC is a simple matter of left or right positioning. Additional poles, either NO or NC, may be easily added at any time
Come in a wide range of input voltages and with coils from 24 Vac to 277 Vac and 12 Vac to 24 Vdc
