Eaton D9PR9BT1 Plug-In-Electromagnetic - 3P, 1PST-1 NO/1 NC, 24 Volt Coil, 25 Amp
Normally In Stock
Code: 265166
Eaton D9PR9BT1 Relay Plug-In-Electromagnetic - Three Pole, Single Pole - Single Throw 1 Normally Open & 1 Normally Closed - 24 Volt Coil, 25 Amp
Condition: New
Usually ships Same Day or Next Day$103.43
Sale Price
$86.19
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Eaton D9PR9BT1 - D9 Series , 24 Vdc coil, Three Pole, Single Throw- Normally Open/Single Pole, Single Throw- Normally Closed contact configuration, Normally Open: 25A, 220 Vac/30 Vdc, Normally Closed: 8A, 220 Vac/30 Vdc rated load, 250 Vac/125 Vdc max. operating voltage
Specifications
Relay Poles
Single Pole
Relay Poles
Three Pole
Component
Relay Plug-In-Electromagnetic
Relay Throws
Single Throw 1 Normally Open & 1 Normally Closed
Coil Voltage Rating
24 Volt
Coil Voltage Max
250 Volt
Manufacturer
Eaton
Relay Load Amperage
25 Amp
Features
Flag indicator allows users to see relay status in either manual or powered condition
Push-to-test button allows for manual operation of relay without the need for coil power
Lock-down door holds pushbutton and contacts in the operate position when activated, for analyzing circuit problems
No contact chattering for momentary voltage drops up to 50% of rated voltage
Finger-grip cover allows operator to remove relays from sockets more easily than conventional relays. This optional clip accessory allows operators to remove relays from sockets more easily than conventional relays
White plastic ID tag/write label allows users to easily identify relays in multi-relay circuits
