Code: 260156
Phoenix Contact 1110155 Power supply UNO2-PS/1AC/48DC/240W
Normally In Stock
UNO2-PS/1AC/48DC/240W Phoenix 1110155 Power supplies with basic functionality Input: 112 VAC -240 VAC,Output: 48 VDC, 2.4 Amp Screw Connections, Mount Type: Din Rail Mount
Condition: New
Usually ships Same Day or Next Day$96.44
Sale Price
$80.37
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1110155 The UNO POWER primary-switched power supply unit is a DIN rail-mounted device with a screw connection that accepts a 1-phase input and provides an adjustable output of 48V DC with a maximum capacity of 5A. Its voltage range can be set between 42V DC and 56V DC, allowing for customizable power supply settings as needed.
Specifications
Power Supply Type
Switching
Power Supply Mounting
Din Rail Mount
Power Supply Voltage Output
48 VDC
Power Supply Amperage Output
5 Amp
Component
Power Supply
Manufacturer
Phoenix Contact
Line
UNO
Power Supply Voltage Input
240VAC
Power Supply Voltage Input
120VAC
Power Supply Amperage Output Range
0-5 Amp
Power Supply Voltage Input Range
112 VAC -240 VAC
Features
Save space in the control cabinet with an extremely narrow overall width of just 45 mm
Save energy, thanks to a high degree of efficiency
Outdoor installation possible, with a wide temperature range of -25°C … +70°C
Simple output voltage monitoring, thanks to the floating DC OK relay contact
