Phoenix Contact 1621326 Test plug PRC 3-TC-FS6 8-21
Normally In Stock
Code: 239054
Phoenix Contact 1621326 - Test plugs - 3 Positions - Cu Alloy - Black - 35 Amp - IP66 , IP68 - Screw Connection - Snap-In Locking
Condition: New
Usually ships Same Day or Next Day$40.74
Sale Price
$33.95
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 1621326 A PRC test plug is available in a standard configuration that includes a black finish and has undergone 2000 plug cycles. It features three positions, with copper wires of varying cross-sectional areas (1.5 mm2 to 6 mm2), and can be manually released. The plug operates at a high voltage of 690 V and supports a maximum current of 35 A, secured via a screw connection suitable for cables with an outside diameter of 8-21 mm in size.
Specifications
Connector Color
Black
Connector Amperage
35 Amp
Connector Material
Cu Alloy
Connector protection
IP66
Connector protection
IP68
Component
Connector
Manufacturer
Phoenix Contact
Number of Positions
3
Sub Component
Test Plugs
Features
Up to 75% smaller in size than industrial connectors with the same rating
Locking mechanism can be unlocked manually or using a tool
Suitable for applications in atmospheres containing salt and in direct sunlight
Ideal for indoor and outdoor use due to weatherproof materials
